| X-Y Cutting Travel* | 4' 4" x 2' 2" |
| Z-Axis Travel (with Motorized Z Axis)* | 8" |
| Table Size (LxW) | 5' 9" x 2' x6" |
| Material Support Slats | 4" x 1/8" Galvanized Steel |
| Maximum Supported Material Load | 400 lbs/sq ft |
| Noise Level | Below 80 dBA at one meter for submerged cutting |
| Speed | 180 in/min (4.57 m/min) |
| Linear Axis Accuracy* | ±0.001” (±0.025 mm) |
| Linear Axis Repeatability* | ±0.001” (±0.025 mm) |
| Ballbar Circularity* | ±0.0025” (±0.064 mm) |
| Electrical Requirements | 3-Phase, 380-480 VAC ±10%, 50-60 Hz |
| Floor Space Dimensions (LxW) | 12' 1" x 6' 3" |
| Height (with standard plumbing) | 8' 0" |
| Operating Weight | 10252 pounds |
| Weight (Tank Empty) | 4300 pounds |
Short Terms and Conditions of Sale (Please contact us for complete Terms and Conditions): Unless otherwise posted, all items are sold AS-IS, WHERE-IS With All Faults. All specifications and locations are subject to change without notice. All items are subject to availability and prior sale.
