| Specs |
230V 50/60Hz 380V 50Hz 415 V 60Hz 460V 50/60Hz |
| Cutting Capacity - Round (Diameter) |
9.84 in (250 mm) |
| Cutting Capacity - Rectangular Work (W x H) |
11.02 x 9.84 in (280 x 250 mm) |
| Cutting Capacity - Rectangular Work (W x H) |
11.81 x 6.89 in (300 x 175 mm) |
| Allowable Loading Capacity |
3,300 lbs. (1,500 kg) |
| Saw Blade - Blade Speed |
Variable 78 - 262 FPM |
| Saw Blade - Blade Size |
1 in x 11 ft 6 in x .035 in |
| Table Load |
2,500 lbs. (1,133.9 kg) |
| Motors - Saw Blade |
5 HP (3.7 kW) |
| Motors - Hydraulic Pump |
1 HP (0.75 kW) |
| Approximate Weight |
2,650 Lbs. (1,200 kg) |
| Approximate Dimensions (L x W x H) |
86 in x 78 in x 52 in (2,184.4 x 1981.2 x 1320.8 mm) |
Equipped With
MARVEL S-250 HA Automatic Horizontal Band Saw
